1064 nm 10 W High Power Polarization Maintaining Tap Isolator
Overview
The High Power Polarization Maintaining Tap Isolator is characterized with low insertion loss, high isolation, high power handling, high return loss, excellent environmental stability and reliability. The Tap Isolator is ideal for fiber laser and instrumentation applications
Parameter | Unit | Value |
Center Wavelength (λc) | nm | 1030 or 1064 |
Operating Wavelength Range | nm | λc ± 10 |
Tap Ratio (Tap IL = - 10 × log (Tap Ratio) + E.L) | % | 0.1 ± 0.05, 1 ± 0.5, 2 ± 0.8, 5 ± 1.0, 10 ± 2.0 |
Min. Extinction Ratio | dB | 20 |
Min. Isolation, λc, All Polarization States | dB | 25 |
Typ. Excess Loss | dB | 0.8 |
Max. Excess Loss | dB | 1 |
Min. Return Loss (Input/Output) | dB | 45/45 |
Max. Average Optical Power | W | 10 |
Max. Peak Power (Pulse Width,10 ns) | kW | 10 |
Max. Tensile Load | N | 5 |
Fiber Type | - | Specified by ordering info |
Operating Temperature | deg. C | + 10 to + 50 |
Storage Temperature | deg. C | 0 to + 60 |
1Output IL = - 10 × log (1-Tap Ratio) + E.L
1All of above value are tested at room temperature @ 23 ℃, unless other specified.
| Ordering Information | Qty | Price | Available |
|---|---|---|---|
Available Configurations and Pricing for 1064 nm 10 W High Power Polarization Maintaining Tap Isolator
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber HI1060 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber HI1060 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber PM 980 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber PM 980 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 HI1060 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 HI1060 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 PM 980 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 1/99 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 PM 980 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber HI1060 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber HI1060 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber PM 980 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked PM 980 Fiber PM 980 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 HI1060 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 HI1060 Fiber Continuous Wave - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 PM 980 Fiber Pulsed - Price: $660 - Stock: 1000
- Configuration: 1064 nm 10 W 10/90 None Bare Fiber 0.75 m Fast Axis Blocked Nufern FUD-3460 PM 980 Fiber Continuous Wave - Price: $660 - Stock: 1000
