ROSA-LC APD200
High-performance ROSA-LC APD200 photodiode with LC receptacle, offering high responsivity, excellent stability, and reliable operation from -40℃ to 105℃. Ideal for high-speed telecom and datacom applications.
Absolute Maximum Ratings | ||||
Parameters | Unit | Symbol | Min. | Max. |
APD Reverse Current | mW | Ir(APD) | - | 3 |
APD Reverse Voltage | V | Vr(APD) | - | Vbr |
Operating Temperature | ℃ | Top | -40 | 105 |
Storage Temperature | ℃ | Tstg | -45 | 125 |
Lead Solder Temperature | ℃ | - | - | 260 |
Lead Soldering Time | s | - | - | 10 |
Transmitter Optical& Electrical Characteristics (T=25ºC) | ||||||
Parameters | Unit | Symbol | Min. | Typ. | Max. | Test Conditions |
Operating Wavelength | nm | λc | 1550 | - | ||
Breakdown Voltage | V | Vbr | 35 | - | 60 | IR = 1mA @ 25℃ |
APD Operating Voltage | V | Vapd | - | Vbr-1 | - | Best Sensitivity |
APD Dark Current | nA | Id | - | - | 30 | Vop=Vbr-1 |
Capacitance | pF | Cj | - | 1.8 | 2 | Vop=Vbr-1, f=1MHz |
Temperature Dependency of VBR | V/℃ | г | 0.1 | 0.12 | 0.15 | ΔVBR/ΔT, TC= -40° C ~ 20℃ |
| Temperature Dependency of VBR | V/℃ | г | 0.05 | 0.08 | 0.12 | ΔVBR/ΔT, TC= 20° C ~ 85 ℃ |
Responsivity | A/W | Res | 30 | - | - | M=20, λ=1535nm, 1uW |
