Singlemode 4-in-1 Visible Laser Diode

Overview

Designed for high-performance integration, an RGB Laser Module delivers precise red, green, and blue laser outputs in a compact, fiber-coupled system. Ideal for applications requiring sharp beam quality, colour control, and modular flexibility, YESWEHAVE’s visible laser systems support advanced imaging, display, and sensing technologies across various industries.

Optical Parameter

Unit

Value

Wavelength

nm

488 ± 5

520 ± 5

638 or 660 ± 5

785± 5

Output Power

mW

0 - 25

0 - 25

0 - 40

0 - 60

Output Power (PM Version)

mW

0 - 20

0 - 20

0 - 30

0 - 40

Extinction Ratio (PM Version)

dB

15

Fiber Type

-

Singlemode / PM Fiber

Fiber Jacket

-

900 μm Loose Tube or 3 mm Cable

Fiber Length

-

1 m or specify

Connector Type

-

FC/APC or specify


Electrical Parameter

Threshold Current (Typ.)

lth/mA

40

50

50/55

35

Operating Current (Typ.)

Iop/mA

105

150

225/135

141

Operating Voltage

Vop/V

6.0

7.0

2.7/2.5

2.1


Other Parameter

Recommended Operating Temperature*

℃

25 ± 5

Storage Temperature

℃

-40 - 75

Max. Soldering Temperature Allowed

℃

260℃, ≤ 3s

*The LDs need to work with TEC to achieve optimal working status.

For more information about product requirements, please contact us at sales@yeswehave.com

Ordering InformationQtyPriceAvailable
Ordering Information
QuantityPriceAvailable
Please select the ordering information to view price.

Available Configurations and Pricing for Singlemode 4-in-1 Visible Laser Diode

  • Configuration: 785, 638, 520, 488 nm FC/UPC 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/UPC Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm FC/APC Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm None Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 638, 520, 488 nm Specify Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/UPC Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm FC/APC Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm None Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: 785, 660, 520, 488 nm Specify Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/UPC Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify FC/APC Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify None 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify None 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify None 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify None 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify None 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify None 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify None Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify None Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify None Specify Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify 250 µm Bare Fiber 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify 250 µm Bare Fiber 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify 250 µm Bare Fiber Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify 900 µm Loose Tube 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify 900 µm Loose Tube 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify 900 µm Loose Tube Specify - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify Specify 0.5 m - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify Specify 1.0 m - Price: $2350 - Stock: 1000
  • Configuration: Specify Specify Specify Specify - Price: $2350 - Stock: 1000
