Absolute Maximum Ratings
Parameters	Unit	Min.			Max.
PD Forward Current	mA	-			10
PD Reverse Voltage	V	-			20
Input Optical Power	dBm	-			3
Operating Temperature	℃	-40			85
Storage Temperature	℃	-40			85
Lead Solder Temperature	℃	-			260
Lead Soldering Time	s	-			10
Optical and Electrical Parameters (Ta=25℃)
Parameters	Unit	Min.	Typ.	Max.			Test Condition
Bandwidth	GHz	1.0	-	-			Vr = 5 V,- 3 dB
Responsivity	A/W	0.85	0.90	-			1550 nm, Vr = 5 V
Dark Current	nA	-	-	1			Vr = 5 V
Total Capacitance	pF	-	-	3.0			Vr = 5 V
Optical Return Loss	dB	-	-	-40			1550 nm
Fiber Pigtail Parameters
Fiber Type	-	Corning SMF-28e (Type ITU-T Ultra)				Corning ZBL
Fiber Bend Radius	mm	≥15				≥10
Fiber Length	m	L ± 0.1 m
Fiber Color	-	Natural or Black
Connector Type	-	None
