LARK-355 Fiber Laser

Lark-355 is the ultraviolet product of lark series at present. It adopts the heat management mode of conduction heat dissipation combined with air convection heat dissipation. Compared with Seal-355-3S, the water circulation cooling system is omitted, and customers can choose multiple lasers of the same level according to the actual situation. Compared with other similar products, in terms of optical parameters, it achieves narrower pulse width. In terms of structural design, smaller size, lighter weight and better appearance; in terms of electrical control design, Strong anti-electromagnetic interference ability, high thermal management efficiency, friendly GUI interactive interface. These characteristics make the product have better structural stability and stronger environmental adaptability, and thus realize the characteristics of good beam quality, high power stability, long life, high consistency, convenient installation, maintenance-free operation and so on.

Parameter

Value

Product Model

Lark-355-3A

Lark-355-5A

Central Emission Wavelength

355 nm

Average Power

> 3W@40kHz

> 5W@40kHz

Pulse Duration

< 18ns@40kHz

Pulse Repetition Rate Range

20 – 200 kHz

Spatial Mode

TEM00

Beam Quality

 ≤ 1.2

Beam circularity

> 90%

Beam Full Divergence Angle

< 2mrad

Beam Diameter

Mon-expanding:

0.45 ± 0.15mm

Mon-expanding:

0.5 ± 0.15mm

Polarization Ratio

> 100:1

Polarization Orientation

Horizontal

Average Power Stability

RMS ≤ 3% @ 24hrs

RMS ≤ 5% @ 24hrs

Pulse to Pulse Energy Stability

RMS ≤ 3% @ 40kHz

RMS ≤ 3% @ 50kHz

Operating Temperature

0 ~ 40℃

Storage Temperature

-15 ~ 50℃

Cooling Method

Air - cooling

Supply Voltage

DC 12 V

Average Power Consumption

< 180W

< 200W

Three - Dimensions (W×D×H)

313 × 144 × 126mm

348 × 144 × 126mm

Weight

6.8 kg
