CW 4000/6000/12000 W Water Cooled Fiber Laser

JPT CW Multi-Module fiber laser(4000W-12000W) is the optimal combination of optical, mechanical, electrical and software components. Through the controlling ports and the controlling software, the operating status of the laser can be monitored in real time, alarm messages can be received in time, and data can be collected. The laser uses water-cooling and shelf case design, with competitive advantage like high energy conversion (electric to light), low power consumption, maintenance free, fiber delivery, and easy to assemble, it is the most suitable laser source for industrial laser welding, cutting and other applications.

Parameter

Unit

Value

Nominal Average Output Power

W

4000

6000

12000

Beam Parameter Product

mm*mrad

3.2 - 4 @ 100 μm

≤ 6.5 @ 100 μm

Central Emission Wavelength

nm

1080 ± 10

Spectral Width@3dB

nm

< 6

Armored Cable Length

m

25

Cooling Method


Water Cooled

Operating Voltage

V

380 ± 10%

Maximum Power Consumption

W

14000

20000

40000

Switch on/off Time

μs

20

Maximum Modulation Frequency

kHz

5

Operation Temperature

10 ~  40

Storage Temperature

-10 ~ 60

N.W

KG

110

120

210

Size (L×W×H)

mm

911 × 370 × 709

1120×674×794
