2000 ± 20 nm Fused Wavelength Division Multiplexer
Overview
The Fused WDM 2000 ± 20 nm provides stable performance in biochemical equipment, industrial lasers, and optical networks. Its robust design ensures long-term reliability and efficient wavelength division in demanding environments
Parameter | Unit | Value | ||
Longer Operating Wavelength | nm | 2000 ± 20 or Specify | ||
Max. Insertion Loss | dB | 0.5 | ||
Min. Isolation | dB | 13 | ||
Max. Polarization Dependent Loss | dB | 0.15 | ||
Shorter Operating Wavelength | nm | 1570 ± 20 | 800 ± 20 | 650 ± 20 |
Max. Insertion Loss | dB | 0.5 | 0.5 | 1.5 |
Min. Isolation | dB | 17 | 17 | 15 |
Thermal Stability | dB/℃ | ≤ 0.002 | ||
Min. Return Loss | dB | 55 | ||
Min. Directivity | dB | 55 | ||
Max. Optical Power (Continuous Wave) | W | 500 | ||
Operating Temperature | ℃ | -40 to +75 | ||
Storage Temperature | ℃ | -40 to +85 | ||
*IL is 0.3 dB higher, RL is 5 dB lower for each connector added.
*Test at central wavelength only.
| Ordering Information | Qty | Price | Available |
|---|---|---|---|
Available Configurations and Pricing for 2000 ± 20 nm Fused Wavelength Division Multiplexer
- Configuration: 1 × 2 1570 & 2000 nm FC/APC 900 μm Loose Tube 1.0 m SMF-28 Ultra - Price: $200 - Stock: 1000
- Configuration: 1 × 2 1570 & 2000 nm Specify 900 μm Loose Tube 1.0 m SMF-28 Ultra - Price: $200 - Stock: 1000
- Configuration: 1 × 2 650 & 2000 nm FC/APC 900 μm Loose Tube 1.0 m SMF-28 Ultra - Price: $200 - Stock: 1000
- Configuration: 1 × 2 800 & 2000 nm Specify 900 μm Loose Tube 1.0 m SMF-28 Ultra - Price: $200 - Stock: 1000
- Configuration: 1 × 2 650 & 2000 nm Specify 900 μm Loose Tube 1.0 m SMF-28 Ultra - Price: $200 - Stock: 1000
- Configuration: 1 × 2 800 & 2000 nm FC/APC 900 μm Loose Tube 1.0 m SMF-28 Ultra - Price: $200 - Stock: 1000
